16 Speed 17"floor Drill Press (Dp43020f-17")

Following Range :
16 Speed 17"Floor Drill Press (DP43020F-17"), Floor drill Press, Pillar drill press, Drilling machine, wooden working drill press


Model: DP43020F
Features of 16 Speed 17"Floor Drill Press (DP43020F-17") :
1) 16 speed
2) The shell of the Motor is aluminium
3) Baking vanish
3) Safe Guard
4) Key chuck
5) Switch can be equipped with European electromagnetic style or American toggle safety key switch
6) Three spoken feed handles
7) Table tilts 90 degree / positive stop at 0

Optional
1) Keyless chuck
2) Compounded handle
3) Built-in swivel light
4) Built-in oil pot
5) Color can be selected by your favourite.

Specification :
Drill Capacity(mm) 25
Chuck Capacity(mm) 20
Collar Diameter(mm) 75
Swing 17"
Spindle Taper MT3
Speed rpm(50Hz) 16(160-3000)
Speed rpm(60Hz) 16(200~3630)
Spindle Travel(mm) 80
Column Diameter(mm) 80
Rack & Pinion YES
Base Size(mm) 485A 290/506A 345
Table Size(mm) 356A 356/A,350
Motor) 1000W
Height(mm) 1635
NW/GW(kg) 81/86
Packing Size(mm) 1410A 540A 250
Units Per 20' Container 144
