Dc Resistance Tester By Jiangsu Jinxiu High Voltage Electric Co.,ltd.

Taking advantage of our advanced production facility and technology setup, we at "JIANGSU JINXIU HIGH VOLTAGE ELECTRIC CO.,LTD." are engaged as manufacturer and exporter of DC Resistance Tester in Yangzhou, Jiangsu, China.

Introduction
KRI9310 DC resistance tester is portable and automatic tester, which is applicable for the inductive test objects (such as distribution transformers, instrument transformers, reactors, etc) and the resistive test objects (such as contactors of switches, contactors of relays, wires, etc).

Features
1)6 ranges of output current for selection;
2)Automatic calculation function, input the test object material (copper/aluminum) and its temperature, the DC resistor tester will automatically calculate the resistance @ standard temperature (20a ,75a or 120a );
3)500 test data storage;
4)USB port to download the test data to USD flash disk;
5)Protection- discharge alarming, over-heat alarming;
6)Professional probes as optional to measure the real-time temperature.


Technical Parameters

RangeResistance measurement
10A3A1A0.3A0.1A5mA
Measure range0~0.1IC0.01~2IC0.03~6IC0.1~20IC0.3~60IC30~20kIC
Accuracy0.2% readings A 0.5I IC
Resolution0.1I IC
BatteryInbuilt lithium-ion polymers battery, 11.1V, 4500mAh
Temperature20a ,75a ,120a standard
Deimension155m(L)*210mm(W)*68mm (H)
Net weight1.66kgs
Probe (optional)Temperature (-99.9a ~199.9a ), accuracy (readingsA 0.5a )
