Dew Point Sensor Fa510 515 - Application: Industrial Use

Monitoring a compressed air refrigeration dryer is critical to increase energy efficiency, ensure product quality, prevent damage to machinery, identify maintenance needs and achieve cost savings. This contributes to the smooth operation of compressed air systems in various industrial applications.

The sensor technology and evaluation electronics of our sensors have undergone continuous improvements. This implies an increased precision at varying ambient temperatures and a higher signal resolution of the sensor. Like their predecessor models, the new dew point sensors are characterized by long-lasting stable and reliable measurement results. The sensor element is insensitive to condensation and is protected from direct contact with contaminated particles by the stainless-steel sintered cap.

Special features of FA 510/515:
Ideal for refrigeration dryer applications with an accuracy of +/- 1A C in the measuring range -20...+50A Ctd.
Gas-independent measurement, also suitable for other, non-corrosive gases
Compact design, ideal for dryer installations
Robust design, protection class IP 66
Condensation-insensitive sensor element
Long-term stability and drift-resistant, thus optimized calibration intervals
Fast adaptation time, especially from dry to wet conditions
BSP, NPT or UNF thread
Measured values available in different units, pressure dew point [A Ctd], temperature [A C], rel. humidity [%rh], abs. humidity [g/mA ], degree of humidity [g/kg], humidity fraction V/V [ppmV/V], water vapor partial pressure [hPa], atmospheric dew point [A Ctd.atm].
On-site sensor diagnostics with handheld device or CS Service Software.

Measuring Range : -100 DegreeC to +20 DegreeC
Gas Type : air and gases
Brand : cs instruments gmbh
Interface Type : Analogue
