Digital Lcd Microscope - Binocular Observation Head With 8-inch Lcd Screen | Built-in Digital Camera, Co-axial Focusing System, Plan Achromatic Objectives

We are a well-reputed firm that manufacture, distribute and supply an extensive range of Digital LCD Microscope in Ahmedabad, Gujarat, India.

Binocular observation head with LCD screen
siedentopf observation head inclined at 30A rotatable at 360A . 8 inch lcd screen. Built-in digital camera with rca, S-video & USB-2 output with 3. 1m resolution. Internal media card reader / writer.

Eyepiece : wide field eyepiece 10x (paired) fov 18mm.

Objectives (color corrected infinite system):

CCIS plan achromatic 4x
CCIS plan achromatic 10x
CCIS plan achromatic 40x (s l)
CCIS plan achromatic 100x oil( s l)

Mechanical body:

Co-axial focusing system with pre-focusing lever & tension adjustment ring
The slow motion has 1div=0. 002mm.
Reverse angle quadruple nose piece revolves on ball bearing.
Mechanical stage size 125mmx135mm having low positioned co-axial controls on ball bearing guide ways.
The transmitted illuminator has 6v-20w halogen lamp with intensity control knob.

Sub stage condenser:
Abbe condenser n. A. 1. 25 with iris diaphragm

Standard accessories:
Grey & blue filters, halogen bulb 6v/20w, styro foam molded pack
