Digital Meiting Point Apparatus 2935/935/934 Application: Laboratory

TECHNICAL SPECIFICATIONS:-
TFT SCREEN : Available with high resolution camera for viewing capillaries (only in Model 2935)
DISPLAY
TEMPERATURE : 0-300 A C
RESOLUTION : 0.1 C (Model -2935 & Model - 935)
1 C (Model -934)
CAPILLARY GLASSTUBE : 100mm long, 0.8 to 1.1mm internal diameter
BOILING POINT : 6x75mm Glass Tube
SAMPLE SIZE : Fine powder properly dried at a temperature considerably below its melting point, 4 to 6 mm high
OIL BATH : Silicon oil bath beaker - 200 ml capacity with ptfe cover fitted with oil immersion heater. It is having three holes for holding
the capillaries, one for boiling point tube and one for thermometer
STIRRER SPEED : Controllable with front knob
POWER : 230V + 10% AC. 50 Hz
DIMENSION (LxBxH) : 370 x 290 x 290mm (Model 2935)
315 x 290 x 290mm (Model 935 & Model 934)
WEIGHT : 12 Kg. (Approx.)
ACCESSORIES:-
a c Box of Capillaries
a c Glass Tubes for Liquid Sample (6 x 75 mm) 2 Nos.
a c Magnetic Capsule
a c Bottle of Silicon Oil - 250 ml
Glass Cylindrical Beaker with ptfe cover fitted with immersion heater
Instruction Manual, Dust Cover
