Electronic Connectors Ty/l-yp Series

Our range of Electronic Connectors TY/L-YP Series use the high reliable hyperboloid socket as the contacts. This connector has the features of low contact resistance, soft force of mating and unmating, antivibration, shock-proof, high reliability, etc. The main technical characteristics is in accordance with Ministry of Railway standard TB/T2716-1996. The type of connection between socket and plug is bayonet coupling. This product is widely used for the connection between electrical and electronic equipments for the railway, electricity, etc. Both plug and receptacle may be mounted with pins or sockets.
Technical Characteristics:
Temperature:-55a i +125a
Relative Humidity: 40A 2a Up to 90%i 95%
Vibration:10i 2000HZi 154m/s2
Shock:300m/s2
Endurance:500 cycles
L-YP Series connectors introduction:
The connector is developed according to the users requirements. It has advantages and functions of electronic connector. Its outer cover with bayonet socket structure is made from high-strength alloy aluminum and has the high intensity. With contact table of "P" connector, it has the characters of wide contact table, fast joint and fast loosing, etc.
Working Temperaturei -40 a ~+85 a
Working Atmosphere Pressurei 99.99K
Pa Relative Humidityi +40 a A 2 a i 90% A 3%
Vibrationi 735m/s2
Assaulti 245m/s2
At odds with the community or the leadershipi 196m/s2
Collidei 10Hz~2000Hz
The acceleration is reachedi 147m/s2
