High Performance Eletric Baking Oven

1. Oven length 60m, divided to 4 temperature zonesi
2. The total power: 950KWi
3. Each zone set up the observation position and lighti
4. Belt width:1350mmi
5. Inside width 1550mmi height 580mmi
6. The thickness of the inside oven 2mmi the thickness of the outer cover 1.5mmi
7. Insulation layer thickness 300mmi
8. Automatic temperature control and independent movement of each zone to relieve stresses when expanding or contacting, and to make sure the temperature inside oven zone stability.
9. Electric control
a. Siemens PLC touching screen
b. Quartz tube heating
c. The whole temperature can be adjusted automatically according to the heat quantity by different biscuits.
d. Temperature range refer to Zone 1 200~350a , Zone 2 220~300a , Zone 3 180~250a , Zone 4 150~200a i The highest can reach to 400a i
g. The touch screen can save hundreds of the production temperature formulas.
