Humidity And Temperature Sensor Module (Mhtc1a)

These Humidity and Temperature Sensor Module (MHTC1A) is designed base capacitive humiture sensor by Ningbo Junrong Electron. This product utilizes humidity sensor capacitance and temperature sensor (LM35, America), with characteristics of stable, high accuracy, quick response, good crossing-over and it also use craftwork of SMD, and so own extremely small body, stable and reliably performance. The quality guarantee time is 12 months.

Application
Electron, pharmaceutical industry, food processing, warehouses, textile, weather, libraries and museum.

Specification
(1) Power supply (vin) DC 5V+-5%
(2) Electrical current 2MA (max 5mA)
(3) Temperature operating range 0 ~ 70c
(4) Humidity operating range 0 ~ 100%RH (dew point)
(5) Humidity measuring range 2 ~ 99%RH
(6) Temperature storing range -20 ~ 85c
(7) Humidity storing range under 95%RH (no dew point)
(8) Humidity measuring Accuracy MHTC1A +/-3%RH ( at 25c, 60%RH )
(9) Temperature testing feature MHTC1A2 +/-1(LM35 integrated temperature sensor)
MHTC1A1 +-1% 10K 3950 resistance
(10) Temperature dependence (reference) +/-0.2%RH/C (5.00V DC, 0-100%RH, at 0-50C)
(11 Voltage dependence (reference) under +/-3%RH
(12) measure: 21.6*33.5*10mm
