Ir Ccd Camera Wpc103

Following Details of IR CCD Camera WPC103 :
Model
WPC103S31
WPC103S32
WPC103S33
WPC103P41

Horizontal Resolution
420TVL
480TVL
540TVL
420TVL

Pick-up Device
1/3"SONY Super HAD CCD
1/3"SONY Super HAD CCD
1/3"SONY Super HAD CCD
1/4'' SHARP

Scanning Area
4.9mm(H)A 3.7mm(V)

Picture Element
PAL:752(H) x582(V); NTSC:768(H) x494(V)

TV System
PAL/NTSC

Minimum Illumination
IR ON 0 lux

S/N Ratio
More than 48dB

Auto Electronic Shutter
PAL:1/50s-1/100.000s

Gamma Characteristic
0.45

Auto Gain Control
Auto

Auto White Balance
Auto

Back Light Compensation
Auto

Synchronous System
Internal Synchronization

Lens Mount
Standard 6mm (4/6/8/12/16mm Can choice)

Video Output
1.0vp-p.75IC,BNG Connector

IR Distance
50 Meters

Protection Rate
Ip66

Power Supply
DC 12V A 10%

Current Consumption
90mA(IR ON MAX 470mA)

Temperature
-30 ~ +50 C
