Mega Ohm Meter - Up To 40 Tω Measurement, Micro-processor Based , High Voltage Insulation Resistance Testing With Acoustic Signaling And Wireless Bluetooth Compatibility
Price:
Get Latest Price
In Stock
Product Specifications
Display | Graphic LCD |
Power | AC/Battery |
Material | Plastic, Metal |
Standards | EN 61557 |
Communication | Bluetooth |
Features | High accuracy, Easy operation, Durable design, Versatile testing, Reliable results, Wide voltage range, Multiple functions |
Product Overview
Key Features
Mega Ohm Meter
Our clients can avail from us at premium quality assortment of Insulation Resistance Meters that are micro-processor based. These are widely used in industrial applications and in electrical utility substations. Owing to their easy installation, compact design, optimum efficiency and high speed response, these meters have gained huge demand among our clients. In addition to this, our clients can avail these high voltage Insulation Resistance Meters from us in various models to suit their exact industrial requirements.
Insulation resistance measurement:
up to 40 T for MIC-10k,
up to 20 T for MIC-5050,
- measurement voltage any in the range of:
50...5000 V for MIC-5050 (50...1000 V at 10 V and 1...5 kV at 25 V),
5010000 V for MIC-10k1 (50...1000 V at 25 V and 1...10 kV at 50 V),
- continuous indication of measured insulation resistance or leakage current,
- automatic discharge of measured object capacitance voltage after the end of insulation resistance measurement,
- acoustic signaling of 5 seconds intervals to facilitate capturing time characteristics,
- adjustable measuring time to 99'59',
- metered T1 , T2and T3 test times for measuring one or two absorption coefficients from the range of 1600 s,
- polarization index (PI), absorption coefficients Ab1, Ab2 and dielectric absorption ratio (DAR) measurement,)
- indication of actual test voltage during measurement,
- 1.2 mA, 3 mA and 5 mA test current,
- insulation resistance measurement using two- or three-wire method,
- measurements with test leads up to 20 m...
- protection against measuring live objects,
- automatic measurement of multiple core cables with the additional AutoISO-5000 adapter (for MIC-10k1 max. voltage 5 kV)
- measurement of capacitance during the measurement of R . ISO
- measurement of temperature (with additional probe - WASONT1),
- step voltage insulation resistance measurement (SV),
- Dielectric Discharge calculation (DD),
- location of damage (burnout),
- digital filters function for measurements in high noise enviroment
- continuity measurement of protective connections and equipotential bonding in accordance with EN 61557-4 with current > 200 mA,
- adjustable limits for measured resistance R and R , ISO CONT
- measurement of leakage current during insulation resistance testing,
- DC and AC voltage measurement in the range of 0...750 V,
- drawing graphs on the display during measurement,
- innovative memory with possibility of description of: measurement points, facilities, names of customers.
- operating with mini Bluetooth keyboard (option),
- graphic LCD 5,6' backlit,
- keyboard backlit,
- power supply from main power line or battery packs,
- built-in fast charger,
- the instruments meet the requirements of the EN 61557 standard.
Our other models are listed below:
MIC-5005/5010
MIC-5000
MIC-2510
MIC-2505
MIC-30
MIC-10
MIC-02
