Microchip PIC16F 8-bit Microcontrollers - MCU
High-Performance RISC CPU:
a c Only 49 Instructions to Learn:
- All single-cycle instructions except branches

a c Operating Speed:
- DC a 32 MHz oscillator/clock input
- DC a 125 ns instruction cycle
a c Up to 8 Kbytes Linear Program Memory

Addressing:
a c Up to 1024 bytes Linear Data Memory Addressing
a c Interrupt Capability with automatic context saving
a c 16-Level Deep Hardware Stack with Optional Overflow/Underflow Reset
a c Direct, Indirect and Relative Addressing modes:
- Two full 16-bit File Select Registers (FSRs)
- FSRs can read program and data memory

Flexible Oscillator Structure:
a c Precision 32 MHz Internal Oscillator Block:
- Factory calibrated to A 1%, typical
- Software selectable frequencies range of 31 kHz to 32 MHz
a c 31 kHz Low-Power Internal Oscillator
a c Four Crystal modes up to 32 MHz
a c Three External Clock modes up to 32 MHz
a c 4X Phase Lock Loop (PLL)

a c Fail-Safe Clock Monitor:
- Allows for safe shutdown if peripheral clock stops
a c Two-Speed Oscillator Start-up
a c Reference Clock Module:
- Programmable clock output frequency and duty-cycle
Special Microcontroller Features:
a c 1.8V-5.5V Operation a PIC16F1825/1829
a c 1.8V-3.6V Operation a PIC16LF1825/1829
a c Self-Programmable under Software Control
a c Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
a c Programmable Brown-out Reset (BOR)
a c Extended Watchdog Timer (WDT)
a c In-Circuit Serial Programming (ICSP) via two pins
a c In-Circuit Debug (ICD) via Two Pins
a c Enhanced Low-Voltage Programming (LVP)
a c Operating Voltage Range:
- 1.8V-5.5V (PIC16F1825/1829)
- 1.8V-3.6V (PIC16LF1825/1829)
a c Programmable Code Protection
a c Power-Saving Sleep mode
Extreme Low-Power Management
PIC16LF1825/1829 with nanoWatt XLP:
a c Sleep mode: 20 nA
a c Watchdog Timer: 500 nA
a c Timer1 Oscillator: 600 nA @ 32 kHz

Analog Features:
a c Analog-to-Digital Converter (ADC) Module:
- 10-bit resolution, up to 12 channels
- Auto acquisition capability
- Conversion available during Sleep
a c Analog Comparator Module:
- Two rail-to-rail analog comparators
- Power mode control
- Software controllable hysteresis
a c Voltage Reference Module:
- Fixed Voltage Reference (FVR) with 1.024V,
2.048V and 4.096V output levels
- 5-bit rail-to-rail resistive DAC with positive
and negative reference selection
Peripheral Highlights:
a c Up to 17 I/O Pins and 1 Input Only Pin:
- High current sink/source 25 mA/25 mA
- Programmable weak pull-ups
- Programmable interrupt-on-change pins
a c Timer0: 8-Bit Timer/Counter with 8-Bit Prescaler
a c Enhanced Timer1:
- 16-bit timer/counter with prescaler
- External Gate Input mode
- Dedicated, low-power 32 kHz oscillator driver
a c Three Timer2-types: 8-Bit Timer/Counter with 8-Bit
Period Register, Prescaler and Postscaler
a c Two Capture, Compare, PWM (CCP) Modules
a c Two Enhanced CCP (ECCP) Modules:
- Software selectable time bases
- Auto-shutdown and auto-restart
- PWM steering
a c Up to two Master Synchronous Serial Port
(MSSP) with SPI and I2CTM with:
- 7-bit address masking
- SMBus/PMBusTM compatibility
a c Enhanced Universal Synchronous Asynchronous
Receiver Transmitter (EUSART) Module
a c mToucha c Sensing Oscillator Module:
- Up to 12 input channels
a c Data Signal Modulator Module:
- Selectable modulator and carrier sources
a c SR Latch:
- Multiple Set/Reset input options
- Emulates 555 Timer applications
