Multilayer Filter Cartridges

Being a client driven firm, we are involved with offering a far reaching of Stainless Steel sintered powder filter cartridges Hyderabad that are recommended for the filtration of air or liquid at higher operating temperatures & corrosive environment. Sintered S.S. cartridges are produced by cold isostatic pressing, which gives high porosity to the material and also stability. They can easily be cleaned or back washed thus having longer shelf life. Sintered filters are able to withstand high differential pressure across the filters.

FEATURES & BENEFITS:

High mechanical strength & good integrity
Good corrosion and thermal resistance
No possibility of media migration
Good permeability
Service life can be prolonged by cleaning and regenerating process

PRODUCT SPECIFICATIONS

Micron Rating
0.5, 1, 3, 5, 10, 25

Length
100 mm to 1000 mm or as per request

Outer Dia
63 mm, other dia available on request

Inner Dia
57 mm

Wall thickness
3 mm

Max operating temp
No constraint
Sterilization
Autoclave
Hot water

121C, 30 min, 10 times
80C, 30 min, 30 times

Effective surface area for sintered filter element
Approx 1000 cm2 per standard 500 mm long cartridge

CONSTRUCTION

Filter media: SS 316L
End Caps: SS 316/ SS 316L
O Ring/ Gaskets: Silicone/ EPDM/ Viton

CONFIGURATION

Double open end- DOE
Code 7S (226- double O Ring / fin)
1- BSP threaded, other end closed

APPLICATIONS

Gas & liquid filtration
Solid catalyst recovery
