Multiple Thread Milling Machining Center Zmc-3000

Condition : New
Origin:Taiwan
Model:ZMC-3000
Longitudinal travel (X) : 3000mm
Cross Travel (Y) : 300mm
Vertical Travel (Z) Travel : Vertical : 500mm & Horizontal:220mm
C-axis Travel : 0.001~360 degree mm
B-axis (Tilting range) : +90/-30 degree
Spindle nose to chuck center : 300mm
Spindle center to column : +50 to -400mm

SPINDLE
Spindle Speed : 8000rpm
Spindle Taper : BT- 40
Spindle motors : 11/15/22 kw
Spindle motors Max. Torque : 83 Nm
X/Y/Z/C axis servo motor : 4.0/4.0/6.0/3.0 kw

DIAMETER
Cutting diameter : 50-300mm
Cutting length : 500-3000mm

C-AXIS
C axis chuck size : 12"(A2-8)
Hole Through C-axis spindle : 70mm
C axis rapid traverse : 6 m/min

FEEDRATE
Rapid traverse (X/Y/Z) And X-Axis driven by Ballscrew : 15/20/20 m/min
Rapid traverse (X/Y/Z) And X-Axis driven by Gear Rack : 24/20/20 m/min
Cutting Feed rate (X/Y/Z/C) : 1~6000 mm/min
MAGAZINE CAPACITY
Tool Selection : Bidirectional random type, shortest path
ATC No. of Tools : 24
Adjacent pockets Max. Tool diameter : A 75mm
Max. Tool diameter : 100mm
Max. Tool weight : 7kg
Max. Tool length : 250mm

TAIL STOCK
Tailstock mandrel travel : 120mm
Taillstock mandrel diameter : A 110mm
Tailstock travel : 2900mm
Distance between center : 3900mm
PUMP
Hydraulic pump : 3HP
Lubrication pump : 0.02kw

MACHINE MEASUREMENT
Height (Approx.) : 3400mm
Length (Approx.) : 7700mm
Width (Approx.) : 3470mm
