Paper Cup Making Machine By Ruian Mingyuan Machinery Co. Ltd.

These Paper Cup Making Machine is an automatic machine with multi-working station, which has the function of photocell detection, failure alarm, counter and the advantages of humanism design, safer operation and easier maintenance.
It produces one-side-PE-film-coated paper cups after running a whole procedure of automatic pre-printed fan-shape-paper feeding, cup-side-body sealing(heater), silicone-oil lubricating(for top curling), bottom punching, bottom pre-heating and pre-folding, main heating, bottom knurling, top curling and cup discharging.
It is an ideal equipment of making hot drinks (tea, coffee, milk) disposable paper cups and ice-cream paper cups etc.
Technical Specification of JBZ-A12 Paper Cup Machine :
a cPaper Cup Size : 2.5--12oz, height cup to 120 mm (mold exchangeable)
a cRaw Material : One-side PE(polyethylene) film coated/laminated paper
a cSuitable paper weight : 135gsm--320 gsm (Recommend 170--280 gsm)
a cRated Productivity : 40---50 pcs / minute
a cTotal Power : 5 KW
a cPower Source : 220V/380V 50Hz or other required
a cN.W :1600KGS
a cTotal Weight : 1800 KgS
a cPackage Size (L x W x H) : 2800 x 1320 x 1800 mm
a cElectric Control Box Size : 730 x 600 x 1300 mm
