Pick And Place Machine Smt880

Owing to our extensive years of industry experience and profound market understanding, we are manufacturing and supplying Pick and Place Machine SMT880 from Coimbatore, Tamil Nadu, India. We keep the extensive array of products sorted to make sure that the delivery commences thoroughly. Furthermore, the packaging prevents damage and ensures the product is kept safe. Since, our entire range is produced by following rules set by global quality regulation standards it is of supreme grade.

Specifications:
Number of feeders : 80
Number of IC tray : 8
Number of cameras : 10
Number of heads : 8
Average power : 1000W
Automatic board : Three-stage track
Guide : Screw guide
Maximum mounting speed : 15000 Pcs/h
Average mounting speed of actual mounting resistance : 12000 Pcs/h
Maximum travel scope in Z axis : 20mm
Maximum circuit board area : 500/ 455mm
Positioning precision : 0.01mm
The buffer range of suction nozzle : 4.5mm
Weight : 600KG
Dimension : 1420*1370*1350mm
Power supply : 110V/220V, 50/60Hz
Compressed air : 0.5-0.6Mpa
Drive motor : Panasonic servo motor
Motion drive system : Panasonic high-speed DSP drive
Recognition mode : Simultaneous recognition of eight heads
Vacuum source of suction nozzle : High-speed on-off vacuum generator with vacuum breaker
