Polypropylene Non Return Valves By Parthiv Polymers

Non Return
Valve - Flanged

Construction
Ball
type design, soft seated

Design & Manufacturing Std.
As Per Manufacturer's Standard

End Connections
Flanged as per ANSI B 16.5 (150#)
as per BS 10 (Table
D/E/F) & Din. Std.

Engineering Options
PTFE Coated Rubber
EPDM Rubber
Viton Rubber on
request

Available M.O.C.
PP (Polypropylene)
HDPE (High Density
Polyethylene)
Isotactic PP
PVDF
(Polyvinylidene Fluoride)







No.

Description

Material

Qty.



01

Top Body

PP / HDPE /
ISOTACTIC PP / PVDF

01



02

Bottom Body

PP / HDPE /
ISOTACTIC PP / PVDF
01



03

Ball

PP / HDPE /
ISOTACTIC PP / PVDF
01



04

Ball Ring

PP / HDPE /
ISOTACTIC PP / PVDF
01



05

Seat Ring

NEOPRENE RUBBER
/ VITON / EPDM

01






All Dimension Are (+-) 2mm






Size

OD

OD1

L

T



1"

120.0

25.0

144.0

17.0



1.1/2"

138.0

40.0

170.0

20.0



2"

162.0

50.0

170.0

22.0



2.1/2"

180.0

65.0

255.0

23.5



3"

202.0

75.0

255.0

23.0



4"

230.0

100.0

302.0

26.0
