Protektor Conformal Coating Spray

PROTEKTOR is USA Military Grade IPC-CC-830C Grade, fast drying, single component conformal coating for application on printed circuit board assemblies. PROTEKTOR protects assembled PCBs from HUMIDITY, FUNGUS and CORROSIONS by forming transparent barriers film on the assembled component. PROTEKTOR coating provides insulation against HIGH VOLTAGE ARCHING. PROTEKTOR is transparent, coated components are easily identified, single component may be replaced by soldering directly through the coating. PROTEKTOR is easy to handle with dry to touch time of 30 minutes. PROTEKTOR is very convenient to apply.

The cured film can be removed by using chlorinated solvents such as methylene chloride or trichloroethane.

DIRECTIONS FOR USE:
1. Cleans surface thoroughly
2. Shake can well before and during the use


Purity: 99.99%
Application: Industrial
Solubility: Non-Soluble in Water
Appearance: Clear Transparent
Taste: Other
Properties:
Specific Gravity: 0.95
Propellent: Non-CFC, Flammable
Temperature Resistance: -70A C to 120A C
Dry to Touch Time: 30 mins
Film Thickness: 26 Microns
Clarity: Clear Transparent
Shelf Life: 18 Months
Grade: IPC-CC-830C
Insulation Resistance after Chamber Test: 2.5 x 10A A Ohms
Breakdown Voltage: 700 V at 26 Microns
Product Type: Conformal Coating
Grade: Military IPC-CC-830C
HS Code: 38140020
Storage: Room Temperature
Shelf Life: 24 Months
Smell: Other
CAS No: 1330-20-7
Poisonous: Yes
Ingredients: Proprietary IP
Usage: Conformal Coating - ProtektorAR is a fast-drying, single-component acrylic lacquer for PCBs, protecting them from harsh environments, moisture, corrosion, dirt, dust, fungus, caustic vapors, thermal and dielectric shocks, chemical reactions, etc.
Physical Form: Liquid
3. Mask areas by tape which are not requiring coating
4. Spray from a distance of 30cm in light even coats
5. For best results spray two thin layers rather than one heavy layer
6. If choking occurs, remove the button and clean with fine wire
