Finotek Shuttle Valve - High Strength Carbon Steel, 35mpa Max Pressure, Threaded Connection | Hydraulic Oil Operated, Bidirectional Flow Control

Finotek Shuttle Valve is operated by hydraulic oil and design for screw-in connection and plate position installation. The SV shuttle valve allows the flow in one each direction and block the flow from the T port, there are a high strength stainless ball in the valve chamber to open and stop each in put pressure at A or B port.

Technical information:
Main Raw Materials:High strength carbon steel or casting Iron
Power:By hydraulic oil
Brand:Finotek or OEM
Max. Operation Pressure:35Mpa
Max. Flow Rate:35L/Min.
Connection?type:Threaded
Oil Medium Temperature:-30 to +80cel. for NBR O-rings
Oil Medium:Mineral oil as per DIN51 524, VDMA 24 568 or rapeseed oil, Viscosity 10 - 400 CST
Recommended Medium Filtration:ISO 4406 Standard, cleanliness class:20/18/15
