Single Shaft Waste Shredder Machine - Capacity: 300-20000 Kg/hr

Single shaft shredders are strong and durable. It is suitable for recycling various bulk solid materials, refractory materials, plastic containers and barrels, and plastic pads. Shredded particles can be as small as 20mm according to different needs. And can provide all kinds of feeding hoppers according to customer needs. The equipment rotates the knife at low speed, low noise and more energy-saving. The single-shaft shredder consists of a moving cutter head and a static cutter to complete the function of shredding materials. The cutterhead is composed of a base shaft and several moving cutter blocks in the shape of a quadrilateral. The moving knife block has 4 cutting edges, which can be replaced. The moving cutter blocks are arranged in V-shape rows along the base shaft, fixed on the base shaft with screws, and rotate together with the base shaft to form a moving cutter head. There are two sets of static knives, which are fixed on the frame. The material is pushed by the horizontal hydraulic cylinder to feed towards the cutter head. The speed is stable and adjustable, and the propulsion force is large and uniform. It is suitable for recycling various bulk solid materials, irregular and difficult-to-handle materials, plastic containers and barrels, tubes, films, fibers, paper, etc. The spindle speed is 45~100 rpm, the work is stable and the noise is low.
