Six Water Filled Ci Series Motor

Our Six Water Filled CI Series Motor is the high durable, reliable. It is built for coupling with submersible multistage high and low load thrust 6a pumps for clean water deep well.

Technical Features of Motors :-
6a WF CI Series submersible Motor are Water Lubricated and easily rewindable
Upper/Lower Bracket and motorbase are in cast iron.
Winding wire poly propylene with insulation Class-B.
Motor shaft is of AISI 420 grade or above.
Corrosion resistant stainless steel Stator Shell.
Flange and shaft protrusion as per NEMA standard.
Water lubricated radial and axial thrust bearing.
Degree of protection: IP 68
Mounting: vertical/horizontal.
Dynamically balanced rotor ensure smooth running.
Solid copper bars inserted in to our piece billet rotor offer great rigidity.
Pressure Compensation diaphragm.
Continuous duty.
Motor cable length: 3m/3core.

Its Operating Limits are :-
Maximum allowable rating voltage fluctuation +6%-10%.
Range: 2.2 Kw to 22.4 Kw(3 to 30 hp)
Speed: 2900 RPM 50 Hz/ 3500RPM 60 HZMaximum Liquid Temperature :50A C
Rotation: Clockwise when viewed from motor end

Its Versions are:-
Three phase 2.2 kw to 45 kw, 380-400-415 Volts / 50 Hz.
Three phase 2.2 kw to 45 kw, 230-380-460 Volts / 60 Hz.
