Product Overview
Key Features
Complete with following features : -
With required motor and accessories.
Specifications:
Sliding table dimension 3200x395 mm
Cast iron table 548x896 mm
Extension table (rear) 952x896 mm
Extension table (front) 830x320 mm
Table size 1500x1726 mm
Round rail 40 mm
Main saw blade (Max.) 400 mm
Main saw bore 30 mm
Max. cutting height at 90 (400mm) 130 mm
Max. cutting height at 45 (400mm) 90 mm
Main motor power (1 ph) 7.5 HP (5.6 kw (3ph)
Main blade speed 3000/4000/5000 rpm
Scoring saw blade 120 mm
Scoring saw blade bore 20 mm
Scoring blade motor power 1 HP (0.75 kw)
Scoring blade speed 8000 rpm
Cutting width 1300 mm
Cutting width adjustment Manual
Main saw blade tilting adjustment Manual
Main saw height adjustment Manual
Scoring saw adjustment manual
Saw guard Simple (overhead guard
as option)
Dust collection system (overhead guard) 120/63mm (120/102mm)
N.W / G.W 546 / 637 Kgs.
All specifications, dimensions & design characteristic are subject to change without prior notice.
