Speed Controllers For Eddy Current Motor Ambient Temperature: 50 Celsius (Oc)
Price: 12,500 INR / Unit
Get LatestPrice
Ambient Temperature | 50 Celsius (oC) |
Sealed Type | Packing seal |
Product Type | Other |
Protect Feature | Totally Enclosed |
Phase | Single Phase |
Product Overview
Key Features
Owing to the expertise of our skilled professionals, we are able to offer Speed Controllers for Eddy Current Motor. The given speed controller is tested in terms of quality so as to deliver a flawless range. This speed controller is developed with optimum quality material and advanced techniques in compliance with set industrial standard. Our speed controller is available from us on numerous specifications as per the demand of customers.
Features:
Wall /Desk mounting
Hassle free functioning
Long service life
Type : Speed Controller
Current : 5 A
Certifications : CE, ISO9001 2015
Analog Output : Yes
Alarm : Yes
Applicable Motor Power Range : for 0.25 HP to 75 HP Eddy Current Motor
Ce Marking : Yes
Setback Function : Yes
Maximum Output : 90 V DC
Accuracy : 1%
Rpm Range : 100 to 1250 RPM and 225 to 2700 RPM
Speed Range : continuous duty speed range 100 to 1250 RPM and 225 to 2700 RPM
Speed Regulation : 2%
Output : 90 V DC 5 Amps
Brand : Application Systems
Usage/Application : Spped controller to control speed of Eddy Current Motor
Torque Stability : 0.2%
Speed Indicator : Percentage analogue
Construction : Wall/Desk mounting
Input Voltage : 240 V AC, +-15%
Ambient Temperature : 50 Deg C
Set Speed : Potentiometer, single turn or 10-turn helical with dial
Features:
Wall /Desk mounting
Hassle free functioning
Long service life
Type : Speed Controller
Current : 5 A
Certifications : CE, ISO9001 2015
Analog Output : Yes
Alarm : Yes
Applicable Motor Power Range : for 0.25 HP to 75 HP Eddy Current Motor
Ce Marking : Yes
Setback Function : Yes
Maximum Output : 90 V DC
Accuracy : 1%
Rpm Range : 100 to 1250 RPM and 225 to 2700 RPM
Speed Range : continuous duty speed range 100 to 1250 RPM and 225 to 2700 RPM
Speed Regulation : 2%
Output : 90 V DC 5 Amps
Brand : Application Systems
Usage/Application : Spped controller to control speed of Eddy Current Motor
Torque Stability : 0.2%
Speed Indicator : Percentage analogue
Construction : Wall/Desk mounting
Input Voltage : 240 V AC, +-15%
Ambient Temperature : 50 Deg C
Set Speed : Potentiometer, single turn or 10-turn helical with dial
Product Specifications
Ambient Temperature | 50 Celsius (oC) |
Sealed Type | Packing seal |
Product Type | Other |
Protect Feature | Totally Enclosed |
Phase | Single Phase |
Speed | 100 to 1250 RPM |
Color | Blue and siemens gray |
Weight | 4 Kilograms (kg) |
Warranty | one year |
FOB Port | FOB Mumbai, JNPT sea port, INDIA |
Payment Terms | Letter of Credit (L/C), Telegraphic Transfer (T/T), Cash in Advance (CID), Cash Advance (CA) |
Supply Ability | 10 Per Week |
Delivery Time | 1 Week |
Packaging Details | Sea worthy wooden packing, fumigated for pests control |
Main Export Market(s) | Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia |
Main Domestic Market | All India |
Certifications | ISO 9001:2015 , CE |
Company Details
APPLICATION SYSTEMS is established in year 2000 at Thane, near Mumbai, manufacturing, various types Dynamometers to test Engines, Motors, Gears & Gear Boxes, Shafts & Axles, Chassis etc. Magnetic Powder Brakes & Clutches, Web Tension Control systems, Load Cells, Welding back up strips & Tapes,
1) Dynamometers - Eddy Current Dynamometers, Powder Dynamometers, Pneumatic Dynamometers, Tandem Dynamometers, AC Regen Dynamometer, Engine Dynamometers, Motor Test Dynamometers, Chassis Dynamometer, Test Benches, Test Rigs.
2) Magnetic Powder Brakes & Clutches - Powder Brakes & Clutches are manufactured in wide rating range, form tiny 0.1 KgM (1 Nm) to Massive 500 KgM (5000Nm), in various cooling versions such as Self Cooled, Forced Air cooled, Fan Cooled & Water Cooled. These are true Torque Control Devices. Torque is strictly proportional to Excitation Current applied to Coil. These devices come with matching electronics to meet your most exacting applications such as Torque Control, Tension Control, Stretch Control, Torque Limit & many more.
3) Web Tension Control systems - Web Tension Control systems for Unwind, Rewind & Intermittent section. Web tension control consist Load cell feed back as well as diametric compensation for accurate tension control. Web Tension Control systems configured using either Motorised or Powder brakes & Clutches.
Tension Controls are used mainly for: UNWIND, PAY OFF, REWIND, TAKE UP INFEED, OUTFEED & Intermittant Sections
For printing machine,
For Lamination & coating machines,
For Slitting machine,
For Wires & Cable machine, Wire cut machines,
For Paper, Plastic Films, Foils, Wires, Cables converting machines,
4) Load cells.- Web Tension Load Cell- Web Tension Sensing Load Cells, Weighing Load Cell, Reaction Torque measurement Load Cells.
5) Welding back up tape - CERBACK Brand Welding back up tapes & strips for one side welding. These are used for ALL kind of WELDING PROCESSES & for ALMOST ALL METALS, for One Side welding. Welding processes such as SMAW, FMAW, GMAW, SAW, CO2, TIG, MIG etc.
By using Weld back up strips, Welding COST is saved approx 50 to 60% whereas welding TIME is saved by 50%. RESULTS are 100% RADIOGRAPHIC WELDING. No Back CHIPPING, No Back GRINDING or Gouging, No PURGING required.
